Heavy-Duty Scissors Lift Power Unit

This single phase, 220 Volt, auto-hoist, AC power unit is the perfect choice of performance and power to meet your commercial needs. AMGO’s Heavy Duty Scissor Lift Power Unit is designed with the same care, efficiency, and quality that customers expect, with the power to do jobs again and again. When your business is providing comprehensive automotive service, turn to the professionals of AMGO to provide the power to keep your business going.

Contact Us Now

Features

  • CSA certified 2.0HP 3450 RPM motor, large torque
  • 220V single-phase 60Hz AC
  • Cartridge high pressure relief valve, the relief pressure is set at 3000 PSI
  • Cartridge high quality high-pressure check valve and release valve, the leakage rate under 3000 PSI does not exceed 2 drops/min
  • 3/8″ SAE oil outlet port
  • Both oil return flow and pressure are adjustable
  • Dual oil line output system, double electromagnetic pressure release
  • Equipped with a 24L square iron oil tank, which can be installed either by hanging or seated
  • 3 years warranty for hydraulic parts, 2 years warranty for electrical parts
Model 071204
Release Mode Electric
Phase 1PH
Current (Amps) 15-18.5
MotorVolt 220V 60Hz
Motor Power 2.0 HP
Pressure (MPA) 25
Rotate Speed (RPM) 3450
Flow (cc/r) 2.1
Oil Tank (L) 24
L: Total Length 683 mm
L1: Total Length 383 mm
