Double Scissor Lift Power Unit

This single phase, 220 Volt, auto-hoist, AC power unit is designed with power in mind. AMGO realizes that when your lift is down, it is not producing for you. Know and trust the professionals at AMGO who built this power unit to help you get the jobs back on the road fast, again and again. This unit can be equipped with a switching valve to achieve twice the lift for your larger job requirements.

Model： 071205

Contact Us Now

Features

  • CSA certified 2.0HP 3450 RPM motor, large torque
  • 220V single-phase 60Hz AC
  • Cartridge high pressure relief valve, the relief pressure is set at 3000 PSI
  • Cartridge high quality check valve and release valve, the leakage rate under 3000 PSI does not exceed 2 drops/min
  • Oil outlet on both sides (3/8″ SAE screw thread)
  • Both oil return flow and pressure are adjustable
  • Electromagnetic pressure relief, equipped with primary and secondary manifold block, double oil outlet oil line check valve, mainly suitable for double scissor lifts
  • Equipped with a 27L square iron oil tank, which can be installed either by hanging or seated
  • 3 years warranty for hydraulic parts, 2 years warranty for electrical parts
Model 071205
Release Mode Electric
Phase 1PH
Current (Amps) 15-18.5
MotorVolt 220V 60Hz
Motor Power 2.0 HP
Pressure (MPA) 25
Rotate Speed (RPM) 3450
Flow (cc/r) 2.1
Oil Tank (L) 17
L: Total Length 625 mm
L1: Total Length 383 mm
