AMGO 408-HP

Professional Deluxe 4-post Parking Lifts, one of the best 4-post parking lifts in the market with extremly high lifting.

Click to download Product Brochure

Click to download Product Manual

Model	408-HP
Lifting Capacity	8,000lbs
Lifting Time	83s(110V) 31s(220V)
A: Overall Length (Inc Ramps)	207″ (5257mm)
B: Overall Length (Not Inc Ramps)	173 1/4″ (4400mm)
C: Overall Width	109 5/8″ (2784mm)
D: Width Between Posts	96″ (2438mm)
E: Max. Lifting Height	87 3/4″ (2227mm)
F: Overall Height	96 5/8″ (2455mm)
G: Minimum Height	6 1/8″(155mm)
H: Max. Underneath Height	83″ (2107mm)
I: Drive-Thru Clearance	81 5/8″ (2074mm)
J: Width Between Runways	37″ (940mm)
K: Outside Edge of Runways	74 3/8″ (1890mm)
Gross Weight	1,704lbs(773kg)
Motor	1.0HP 110V/60Hz; 2.0HP 220V/60Hz
