AMGO PRO-14A

The PRO-14A provides the same lifting capacity as the PRO-14 but with turn plates to do alignment work. It is built to commercial grade standards which will provide many years of service.

Click to download Product Brochure

Click to download Product Manual

Description

Features

14,000 lbs capacity.
Air-Lock Released for Safety and Reliability of Convenient Operation
Mechanical self lock and cable breaking protection.
1/2″ Aircraft quality cable.
Skid proof diamond platform.
Hydraulic cylinders are designed and Made to high quality standards.
Adjustable lifting platform: Off-side platform can be adjusts the mounting position left or right as required. The standard distance between two platforms is 47”(1194mm) and maximum distance is 54 1/2”(1385mm).
Optional Rolling Jacks:
- RJ-8A: pneumatic hydraulic type 8,000lbs (3,500kg)
- RJ-10A: pneumatic hydraulic type 10,000lbs (4,500kg)
More choices:
- Optional led lights: No. 40103
- Optional extension kits: No. 41403
- Optional air line kit: No. 40102
Five-year Warranty on Steel Components, Three-year Warranty on Hydraulic Parts and Two Years on electrical components

Model	PRO-14A
Style	Alignment
Lifting Capacity	14,000 lbs (6,500kg)
Lifting Time	76s
A: Overall Length (Inc.Ramps)	257″ (6528mm)
B: Overall Length (No.Ramps)	216 1/2″ (5500mm)
C: Overall Width	130 7/8″ (3324mm)
D: Width Between Columns	116″ (2946mm)
E: Max. Lifting Height	75 3/8″ (1915mm)
F: Overall Height	86″ (2185mm)
G: Minimum Height	9 7/8″ (250mm)
H: Max. Underneath Height	66 3/4″ (1695mm)
I: Drive-Thru Clearance	102 1/8″ (2592mm)
J: Width Between Runways	47″ (1194mm), Max. 54 1/2″ (1385mm)
K: Outside Edge of Runways	87″ (2210mm), Max. 94 1/2″ (2401mm)
L: Min. Four Wheel Align	92 1/2″ (2350mm)
M: Max. Four Wheel Align	169 5/8″ (4310mm)
N: Max. Two Wheel Align	175 1/4″ (4450mm)
Gross Weight	3,400 lbs (1,542kg)
Motor	2.0HP, 220V/60Hz Single Phase
