AMGO PRO-12ASX

Need alignment work done on everyday vehicles? This is the lift for you! With double safety locks to ensure you and your vehicle are always safe, you can feel secure with your work.

Click to download Product Brochure

Click to download Product Manual

Description

Features

12,000 lbs lifting capacity.
Air-released safety lock for convenient operation and reliability.
Mechanical self lock and cable breaking protection.
3/8″ Aircraft quality cable.
Optional adjustable turnplate pockets to fit different wheel bases.
Skid proof diamond platform.
Hydraulic cylinders are designed and Made to high quality standards.
Adjustable lifting platform: Off-side platform can be adjusts the mounting position left or right as required. The standard distance between two platforms is 43 1/4”(1100mm) and maximum distance is 53 3/4”(1365mm).
Strict quality control of cylinders with flow restrictors to keep a constant low speed.
Optional Rolling Jacks:
- J6H 6,000lbs manual control
- J6A 6,000lbs pneumatic pump
Front Turnplates No. 40101
More choices:
- Optional led lights: No. 40103
- Optional extension kits: No. 40903
- Optional air line kit: No. 40102
Five-year Warranty on Steel Components, Three-year Warranty on Hydraulic Parts and Two Years on electrical components

Model	PRO-12ASX
Style	Alignment
Lifting Capacity	12,000 lbs (5,500 kg)
Lifting Time	45s
A: Overall Length (Inc.Ramps)	232 5/8″ (5910mm)
B: Overall Length (No.Ramps)	196 3/4″ (4998mm)
C: Overall Width	132 1/8″ (3356mm)
D: Width Between Columns	118 1/8″ (3000mm)
E: Max. Lifting Height	75 3/8″ (1915mm)
F: Overall Height	86″ (2185mm)
G: Minimum Height	8 5/8″ (220mm)
H: Max. Underneath Height	67 7/8″ (1724mm)
I: Drive-Thru Clearance	104 1/8″ (2646mm)
J: Width Between Runways	43 1/4″ (1100mm), Max. 53 3/4″ (1365mm)
K: Outside Edge of Runways	83 1/4″ (2116mm), Max. 93 3/4″ (2381mm)
L: Min. Four Wheel Align	81 7/8″ (2080mm)
M: Max. Four Wheel Align	151 5/8″ (3850mm)
N: Max. Two Wheel Align	157 1/2″ (4000mm)
Gross Weight	2,798 lbs (1,269 kg)
Motor	2.0HP, 220V/60Hz Single Phase
