AMGO PRO-40

The PRO-40 is AMGO’s heaviest-duty truck lift. This makes it the most powerful lift out of our selection with a 40,000lb lifting capacity. Featuring a high-quality design with safety features to ensure safe operation, anyone working on a massive vehicle should consider this machine. Coming Soon.

Click to download Product Brochure

Click to download Product Manual

Description

Features

40,000 lbs capacity.
Air-released safety lock for convenient operation and reliability
Mechanical self lock and cable breaking protection.
3/4″ Aircraft quality cable.
Skid proof diamond platform.
Hydraulic cylinders are designed and made to high quality standards.
Strict quality control of cylinders with flow restrictor for a stable and smooth operational speed.
Optional Rolling Jacks:
- RJ-20A 20,000lbs pneumatic pump

Model	PRO-40
Lifting Capacity	40,000 lbs
Lifting Time	176s
A: Overall Length (Inc.Ramps)	366 1/8″ (9300mm)
B: Overall Length (No.Ramps)	315 1/2″ (8014mm)
C: Overall Width	161 3/8″ (4100mm)
D: Width Between Columns	143 7/8″ (3654mm)
E: Max. Lifting Height	74 3/4″ (1900mm)
F: Overall Height	91 7/8″ (2332mm)
G: Minimum Height	10 1/2″ (265mm)
H: Max. Underneath Height	65 7/8″ (1674mm)
I: Drive-Thru Clearance	129 7/8″ (3298mm)
J: Width Between Runways	58 7/8″ (1496mm)
K: Outside Edge of Runways	114 7/8″ (2916mm)
Gross Weight	8,320 lbs (3,774 kg)
Motor	2.0HP, 220V/60Hz Single Phase
