AMGO PRO-12

Use AMGO’s PRO-12 to take advantage of quick set-up for undercarriage repairs many other service and safety features to meet the needs of garage and shop owners with a 12,000 lbs lifting capacity.

Click to download Product Brochure

Click to download Product Manual

Description

Features

12,000 lbs capacity.
Air-released safety lock for convenient operation and reliability.
Mechanical self lock and cable breaking protection.
1/2″ Aircraft quality cable.
Skid proof diamond platform.
Hydraulic cylinders are designed and Made to high quality standards.
Adjustable lifting platform: Off-side platform can be adjusts the mounting position left or right as required. The standard distance between two platforms is 43 1/4”(1100mm) and maximum distance is 51 1/8”(1300mm).
Strict quality control of cylinders with flow restrictor for a stable and smooth operational speed
Optional Rolling Jacks:
- J6H 6,000lbs manual control
- J6A 6,000lbs pneumatic pump
More choices:
- Optional led lights: No. 40103
- Optional extension kit: No. 41203
- Optional air line kit: No. 40102
Five-year Warranty on Steel Components, Three-year Warranty on Hydraulic Parts and Two Years on electrical components

Model	PRO-12
Style	Non-Alignment
Lifting Capacity	12,000 lbs (5,500 kg)
Lifting Time	63s
A: Overall Length (Inc.Ramps)	236 5/8″ (6012mm)
B: Overall Length (No.Ramps)	200 3/4″ (5100mm)
C: Overall Width	126 1/4″ (3208mm)
D: Width Between Columns	112 1/4″ (2852mm)
E: Max. Lifting Height	73 1/2″ (1865mm)
F: Overall Height	86″ (2185mm)
G: Minimum Height	6 5/8″ (170mm)
H: Max. Underneath Height	67 7/8″ (1724mm)
I: Drive-Thru Clearance	98 3/8″ (2498mm)
J: Width Between Runways	43 1/4″ (1100mm), Max. 51 1/8″ (1300mm)
K: Outside Edge of Runways	83 1/4″ (2116mm), Max. 91 1/8″ (2316mm)
Gross Weight	2,319lbs (1,052kg)
Motor	2.0HP, 220V/60Hz Single Phase
